TG Brushless Motor Series

ThinGap’s TG Line of Motors

Highest power density motor design with high torque and inherent high speed capability.

• “Classic ThinGap” topology
• Optimized for highest power density with high torque capability
• Dual inside and outside rotating back iron
• Zero cogging, patented iron-less composite stator
• Available in frameless kit form or motor assembly with shaft and bearings
• Typically Hall effect sensors are pre-aligned and factory-installed, encoders option
  is available on some models
• Sizes from 50 mm to 1 meter, power levels range from Milli to Mega Watts
• 3 phase brushless, precision sinusoidal waveform
• Fail-safe wrap available over rotor magnets for ultra reliability
• Fully encapsulated stator windings



Available Products

Average Lead Time: 8-10 weeks

TG Sub-Series	Motor Model	Continuous Torque (N-m)	Max Speed (RPM)	Frameless STEP / Drawing	Framed STEP / Drawing	Alternate Framed STEP / Drawing
2 Series 2" OD	TGI 231X	0.74	6,500
	TGO 232X	0.35	16,000
	TGO 233X	0.69	16,000
	TGD 234X	1.02	6,500
	TGI 046	0.71	3,300		N/A	N/A
3 Series 3" OD	TG 303X	0.14	30,600			N/A
	TG 304X	0.19	28,400			N/A
	TG 305X	0.21	17,900			N/A
4 Series 4" OD	TGO 110	0.99	4,000		N/A	N/A
5 Series 5" OD	TG 513X	1.68	18,400			N/A
	TG 514X	2.65	13,900			N/A
	TG 515X	3.57	10,300			N/A
7 Series 7" OD	TG 713X	2.98	13,700			N/A
	TG 714X	4.26	10,800			N/A
	TG 715X	4.83	10,300			N/A
	TGO 190	9.46	6,000		N/A	N/A
